Description

This Continuous Belt Dryer is a continuous penetrating flow drying equipment for drying strip and particles.It is also suitable for the materials such as de-watering vegetable, herbal medicine of traditional Chinese medicine ,fruit and others.it is large scale drying machine with fast drying speed, high evaporation capacity and good product quality.

Principle:

The materials are uniformly distributed on the mesh belt by the material feeder. The mesh belt generally adopts 12-60 mesh stainless steel mesh and it is drawn by a transmission device and move inside the dryer . The dryer is composed of several sections. For each section, the hot air is circulated separately. Part of exhausted gas is exhausted by a special moisture exhaust blower. The waste gas is controlled by an adjustment valve. The hot air passes through the mesh-belt covered with bring water material away. The mesh-belt moves slowly, running speed can be freely adjusted according to the material property. The final products after the drying process will fall into the material collector continuously. The top and low circulation units can be freely equipped according to the user’s requirements. The number of section might be selected according to the production demands.

Product technical parameter:

Model	DWT1.6-Ⅰ	DWT1.6-Ⅱ	DWT1.6-Ⅲ	DWT2-Ⅰ	DWT2-Ⅱ	DWT2-Ⅲ
Belt Width (m)	1.6	1.6	1.6	2	2	2
Drying length(m)	10	10	8	10	10	8
Thickness of the material(mm)	≤100	≤100	≤100	≤100	≤100	≤100
Temperatue(℃)	50-150℃	50-150℃	50-150℃	50-150℃	50-150℃	50-150℃
Heat Exchange Area(m2)	525	398	262.5	656	497	327.5
Steam Pressure( Mpa）	0.2-0.8	0.2-0.8	0.2-0.8	0.2-0.8	0.2-0.8	0.2-0.8
Drying time(h)	0.2-1.2	0.2-1.2	0.2-1.2	0.2-1.2	0.2-1.2	0.2-1.2
Power(KW)	15.75	12.75	9.55	20.75	16.75	12.55
Size(m)	12×1.81×1.9	12×1.81×1.9	10×1.81×1.9	12×2.4×1.92	12×2.4×1.92	10×2.4×1.92
